AW139 EMS



Leonardo AW 139 EMS

Available Nation Wide

Cost $22,000,000 to $28,000,000

The AW-139 is a medium twin-engine helicopter with a maximum takeoff weight of 6,400–6,800 kg, capable of carrying up to 15 passengers and featuring advanced avionics and high-performance engines.

General Information

• Manufacturer: AgustaWestland (Leonardo Helicopters)
• First Flight: February 3, 2001
• Production Start: 2003
• Certification: FAA type certification in December 2004
• Crew: 1–2 pilots
• Passenger Capacity: Up to 15 passengers in a spacious cabin, configurable with armchairs or fixed seats
• Mission Roles: Executive transport, EMS, SAR, law enforcement, offshore transport, multi-role operations

Dimensions

• Length (rotors turning): 16.66 m (54 ft 8 in)
• Overall Height: 4.98 m (16 ft 4 in)
• Main Rotor Diameter: 13.80 m (45 ft 3 in)
• Cabin: Largest in its class, low noise and vibration, wide hinged doors with retractable step

Weight and Load

• Maximum Takeoff Weight (MTOW): 6,400 kg standard / 6,800 kg optional (14,110–14,991 lb)
• Maximum Useful Load: 2,650–3,050 kg (5,843–6,724 lb)
• Fuel Capacity: Standard 1,568 L (414 US gal), Auxiliary 500 L (132 US gal),

Powerplant

• Engines: 2 × Pratt & Whitney Canada PT6C-67C
• Takeoff Power (5 min): 1,679 shp (1,252 kW) per engine
• Maximum Continuous Power: 1,531 shp (1,142 kW) per engine
• O.E.I. Max Contingency Power: 1,872 shp (1,396 kW)
• Transmission Rating: Takeoff 2,200 shp, Continuous 2,000 shp, O.E.I. min 1,600 shp, O.E.I. max continuous 1,400 shp

Performance

• Maximum Cruise Speed (SL): 306 km/h (165 kts)
• VNE (Never Exceed Speed): 310 km/h (167 kts)
• Rate of Climb (SL): >10.9 m/s (>2,140 ft/min)
• Hovering IGE (TOP): 4,682 m (15,360 ft)
• Hovering OGE (TOP): 2,478 m (8,130 ft)
• Service Ceiling (MCP): 6,096 m (20,000 ft)
• Maximum Range: 1,250 km (675 nm)
• Maximum Endurance: 5 h 56 min (with 1,654 kg fuel, no reserve, at 6,000 ft),

Avionics and Systems

• Avionics: Honeywell Primus Epic fully integrated system
• Autopilot: 4-axis digital AFCS
• FADEC: Full authority digital engine control for optimized safety and engine management
• Optional Features: Auxiliary fuel tanks, rescue hoists, cargo hooks, search and weather radar, ice protection, external cameras, and searchlights

Cabin and Comfort

• Interior: Large, unobstructed cabin with low noise and vibration
• Seating Configurations: Flexible seating for 5–15 passengers, including armchairs and fixed seats
• Amenities: Telecommunications, entertainment systems, workspace, refreshment area, and stowage

  The AW-139 remains a market-leading intermediate twin-engine helicopter, combining high performance, safety, and versatility for multi-role operations worldwide

Call Roberts Yachts and Collectables.com or call 506-906-4152. Let’s get you something great.
